product
Ultrasonic Gas Meter
Ultrasonic gas meter is a new type of gas metering terminal, which uses the time difference of ultrasonic transmission in the medium to measure the gas flow. It is mainly used to measure the gas flow in the pipeline. It uses the wireless communication technology such as GFSK, LoRa, GPRS, NB-ioT to realize the functions of step gas price, wireless remote transmission, remote valve control, abnormal flow monitoring, etc.The cost of human resources and network deployment for gas companies has been greatly reduced.
Technical parameters
Technincal Parametes
ItemUnitModel and specification
RXC02-WB-G6
RXC02-WB-G10
RXC02-WB-G16
RXC02-WB-G25
Measuring Rangem3/h
0.06~10
0.1~16
0.16~25
0.25~40
Total Pressure LossPa≤375
Interface center distancemm150
180
Service temperature℃
-10~40
Accuracy/class 1.5
TightnesskPaInput air 1.5 times the maximum working pressure for five minutes without leakage
Valve Life Cycle次≥10000
Anti-Explosion Level/EXib IIBT3 Gb
IP Degree/IP65
Maximum CurrentmA500
Minimum Graduationm30.01


Dimension ：

Model / SizeMSLBHDWeight （kg）

RXC02-WB-G6

RXC02-WB-G10

RXC02-WB-G16

G1-1/2150246110.5173.550.52.3
RXC02-WB-G25G2
180
330
167
244
75
3.0


Product size
